Savox

Discontinued - Use SW1211SGP-BE - SW1211SG-BE - Waterproof High Voltage Digital Servo 0.08sec / 347.2oz @ 7.4V - Black Edition

$92.99$114.49
  • SAVSW1211SG-BE-Waterproof-High-Voltage-Digita
  • SAVSW1211SG-BE-Waterproof-High-Voltage-Digita
  • Discontinued - Use SW1211SGP-BE - SW1211SG-BE - Waterproof High Voltage Digital Servo 0.08sec / 347.2oz @ 7.4V - Black Edition

Savox

Discontinued - Use SW1211SGP-BE - SW1211SG-BE - Waterproof High Voltage Digital Servo 0.08sec / 347.2oz @ 7.4V - Black Edition

$92.99$114.49
1

Description

The SW-1211SG-BE Servo is an extremely versatile waterproof servo that's a great upgrade to standard RTR servos and fits many conditions where use is vital in rain, sleet, or snow.



Features:

  • Waterproof construction for harsh elements.
  • Strong unique steel gears provide durability and assurance.
  • Capable of HV operation.
  • Ideal for 1/10 vehicles and boats

    •

    Specifications:

  • Torque @ 6v - 15.0kg/208.3oz-in
  • Torque @ 7.4v - 25.0kg/347.2.0oz-in
  • Torque @ 8.4v - 30.0kg/416.6oz-in
  • Speed @ 6v - 0.10 sec/60 deg
  • Speed @ 7.4v - 0.08 sec/60 deg
  • Speed @ 8.4v - 0.07 sec/60 deg
  • Dimensions L x W x H (mm): 40.6 x 20.7 x 42.0
  • Weight: 71g

    • Technical Details

  • Operating Temperature: 14° - 122°F (-10° - 50°C)
  • Running Current (no load): 120mA @6.0V, 150mA @7.4V
  • Stall Current (at locked): 6000mA @6.0 V, 7400mA @7.4V
  • Idle Current: 5mA @4.8V, 5mA @6.0V
  • Wire Length: 150 ± 5mm
  • Output Gear Spline: 25 Tooth
  • Bearings: 2BB
  • Operating Travel: 100° (1000 → 2000 µ second)
  • Neutral Position: 1500 µ second
  • Pulse Width Range: 800 → 2200 µ second
  • Maximum Travel: Appx 130° (900 → 2100 µ second)
  • Refresh Rate: 333 Hz
  • Motor Type: Coreless

    • 1 Year Warranty

    Savox servos are backed with a warranty for 1 year after purchase (see warranty page for details)
